creates connections using clockUtils' TcpSocket More...

Inheritance diagram for m2etis::wrapper::clocktcp::clockTcpWrapper:

Public Member Functions
	clockTcpWrapper (const std::string &listenIP, const uint16_t listenPort, const std::string &connectIP, const uint16_t connectPort)
	starts a TcpSocket connection listening More...

	~clockTcpWrapper ()
	closes socket and all its connections More...

void	send (const message::NetworkMessage< net::NetworkType< net::clockTCP >>::Ptr msg, net::NodeHandle< net::NetworkType< net::clockTCP >>::Ptr_const hint)
	sends a message More...

net::NodeHandle< net::NetworkType< net::clockTCP > >::Ptr	getSelfNodeHandle () const
	returns pointer with data More...

void	registerMessageType (const message::MessageType type, const bool ack) const
	Doesn't do anything right now. More...

Public Member Functions inherited from m2etis::net::NetworkInterface< net::NetworkType< net::clockTCP > >
virtual	~NetworkInterface ()

void	setCallback (NetworkCallbackInterface< net::NetworkType< net::clockTCP > > *cb)
	Sets the callback-object on which the defined callbacks will be called. More...

virtual void	send (const typename message::NetworkMessage< net::NetworkType< net::clockTCP > >::Ptr msg, typename NodeHandle< net::NetworkType< net::clockTCP > >::Ptr_const hint)=0
	Sends a message to the node which is responsible for the given key. Provide a hint for better routing. More...

virtual void	registerMessageType (const typename net::NetworkType< net::clockTCP >::MessageType type, const bool ack) const =0
	register a messagetype. Only registered types are sent. More...

Additional Inherited Members
Protected Attributes inherited from m2etis::net::NetworkInterface< net::NetworkType< net::clockTCP > >
net::NetworkCallbackInterface< net::NetworkType< net::clockTCP > > *	_callback
	returns an array of count neighbor nodes with priority to closer nodes. More...

Detailed Description

creates connections using clockUtils' TcpSocket

Definition at line 49 of file clockTcpWrapper.h.

Constructor & Destructor Documentation

m2etis::wrapper::clocktcp::clockTcpWrapper::clockTcpWrapper	(	const std::string &	listenIP,
		const uint16_t	listenPort,
		const std::string &	connectIP,
		const uint16_t	connectPort
	)

starts a TcpSocket connection listening

m2etis::wrapper::clocktcp::clockTcpWrapper::~clockTcpWrapper ( )

closes socket and all its connections

net::NodeHandle<net::NetworkType<net::clockTCP> >::Ptr m2etis::wrapper::clocktcp::clockTcpWrapper::getSelfNodeHandle ( ) const

inlinevirtual

returns pointer with data

Definition at line 72 of file clockTcpWrapper.h.

void m2etis::wrapper::clocktcp::clockTcpWrapper::registerMessageType	(	const message::MessageType	type,
		const bool	ack
	)		const

Doesn't do anything right now.

void m2etis::wrapper::clocktcp::clockTcpWrapper::send	(	const message::NetworkMessage< net::NetworkType< net::clockTCP >>::Ptr	msg,
		net::NodeHandle< net::NetworkType< net::clockTCP >>::Ptr_const	hint
	)

sends a message

Parameters

[in]	msg	Message to be sent
[in]	hint	A hint on the next hop to be used (not used in this wrapper)

The documentation for this class was generated from the following file:
