This is the interface that should be used for all Order Strategies It specifies all functions that shold be overloaded in every strategy as well as some commonly needed functions. More...

#include <BaseOrder.h>

Inheritance diagram for m2etis::pubsub::order::BaseOrder< NetworkType >:

Public Member Functions
	BaseOrder (PubSubSystemEnvironment *pssi, bool isRoot)

virtual	~BaseOrder ()

void	configureCallback (const boost::function< void(uint64_t, msgProcess)> &func)
	used to set the function to be called when a message should be send to the next processing stage call this function with the id given in receive() to deliver the appropriate message More...

void	setHn (const typename NetworkType::Key &self)
	sets the hostname of the current node More...

void	configureSendCallback (const boost::function< void(message::OrderInfo::Ptr, const typename NetworkType::Key &, ControlTarget)> &func)
	with this function, new messages can be sent directly to nodes More...

void	setRoot (bool b)
	sets whether this node is the root node. Several strategies need this to determind the sequencer More...

virtual bool	hasPending ()=0
	returns whether some messages are still waiting More...

virtual bool	configureOrderInfo (uint64_t id, const message::ActionType mtype, typename message::OrderInfo::Ptr ptr, const typename NetworkType::Key &rec)=0
	called for every message to be sent More...

virtual bool	processControlPayload (typename message::OrderInfo::Ptr ptr, const typename NetworkType::Key &sender)=0
	called for every ControlMsg that arrived More...

virtual void	processSubscribePayload (typename message::OrderInfo::Ptr ptr, const typename NetworkType::Key &sender)=0
	called for every SubscribeMsg that arrived More...

virtual void	processPublishPayload (typename message::OrderInfo::Ptr ptr, const typename NetworkType::Key &sender)=0
	called for every PublishMsg that arrived More...

virtual void	processNotifyPayload (typename message::OrderInfo::Ptr ptr, const typename NetworkType::Key &sender)=0
	called for every NotifyMsg that arrived More...

virtual void	receive (uint64_t id, typename message::OrderInfo::Ptr ptr, const typename NetworkType::Key &sender)=0
	called for every message that is ready to be delivered More...

virtual void	notifyRemovedMessage (typename message::OrderInfo::Ptr ptr, const typename NetworkType::Key &receiver)=0
	notified when message dropped by filter or validity strategy More...

Protected Attributes
PubSubSystemEnvironment *	pssi_

bool	isRoot_
	true if this node is the root node More...

NetworkType::Key	hn
	hostname of the node More...

boost::function< void(uint64_t, msgProcess)>	function_
	stores the function to be called for delivering More...

boost::function< void(message::OrderInfo::Ptr, const typename NetworkType::Key &, ControlTarget)>	sendMsg_
	stores the function to send new messages This function will send a newly created control message containing the given OrderStruct to the specified sender. The Tree ensures that this message will be sent to the specified receiver and will not be processed by any other strategie. More...

Detailed Description

template<class NetworkType>
class m2etis::pubsub::order::BaseOrder< NetworkType >

This is the interface that should be used for all Order Strategies It specifies all functions that shold be overloaded in every strategy as well as some commonly needed functions.

Definition at line 39 of file BaseOrder.h.

Constructor & Destructor Documentation

template<class NetworkType >

m2etis::pubsub::order::BaseOrder< NetworkType >::BaseOrder	(	PubSubSystemEnvironment *	pssi,
		bool	isRoot
	)

inline

Definition at line 41 of file BaseOrder.h.

template<class NetworkType >

virtual m2etis::pubsub::order::BaseOrder< NetworkType >::~BaseOrder ( )

inlinevirtual

Definition at line 42 of file BaseOrder.h.

Member Function Documentation

template<class NetworkType >

void m2etis::pubsub::order::BaseOrder< NetworkType >::configureCallback ( const boost::function< void(uint64_t, msgProcess)> & func )

inline

used to set the function to be called when a message should be send to the next processing stage call this function with the id given in receive() to deliver the appropriate message

Definition at line 48 of file BaseOrder.h.

template<class NetworkType >

virtual bool m2etis::pubsub::order::BaseOrder< NetworkType >::configureOrderInfo	(	uint64_t	id,
		const message::ActionType	mtype,
		typename message::OrderInfo::Ptr	ptr,
		const typename NetworkType::Key &	rec
	)

pure virtual

called for every message to be sent

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

void m2etis::pubsub::order::BaseOrder< NetworkType >::configureSendCallback ( const boost::function< void(message::OrderInfo::Ptr, const typename NetworkType::Key &, ControlTarget)> & func )

inline

with this function, new messages can be sent directly to nodes

Definition at line 62 of file BaseOrder.h.

template<class NetworkType >

virtual bool m2etis::pubsub::order::BaseOrder< NetworkType >::hasPending ( )

pure virtual

returns whether some messages are still waiting

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

virtual void m2etis::pubsub::order::BaseOrder< NetworkType >::notifyRemovedMessage	(	typename message::OrderInfo::Ptr	ptr,
		const typename NetworkType::Key &	receiver
	)

pure virtual

notified when message dropped by filter or validity strategy

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

virtual bool m2etis::pubsub::order::BaseOrder< NetworkType >::processControlPayload	(	typename message::OrderInfo::Ptr	ptr,
		const typename NetworkType::Key &	sender
	)

pure virtual

called for every ControlMsg that arrived

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

virtual void m2etis::pubsub::order::BaseOrder< NetworkType >::processNotifyPayload	(	typename message::OrderInfo::Ptr	ptr,
		const typename NetworkType::Key &	sender
	)

pure virtual

called for every NotifyMsg that arrived

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

virtual void m2etis::pubsub::order::BaseOrder< NetworkType >::processPublishPayload	(	typename message::OrderInfo::Ptr	ptr,
		const typename NetworkType::Key &	sender
	)

pure virtual

called for every PublishMsg that arrived

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

virtual void m2etis::pubsub::order::BaseOrder< NetworkType >::processSubscribePayload	(	typename message::OrderInfo::Ptr	ptr,
		const typename NetworkType::Key &	sender
	)

pure virtual

called for every SubscribeMsg that arrived

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

virtual void m2etis::pubsub::order::BaseOrder< NetworkType >::receive	(	uint64_t	id,
		typename message::OrderInfo::Ptr	ptr,
		const typename NetworkType::Key &	sender
	)

pure virtual

called for every message that is ready to be delivered

Parameters

[in]	id	Id to reference the message later
[in]	ptr	Pointer to the OrderStruct of the message
[in]	sender	containts the sender of the message

Implemented in m2etis::pubsub::order::GMSOrder< NetworkType, Timeout >, m2etis::pubsub::order::MTPOrder< NetworkType, Timeout, deli >, m2etis::pubsub::order::DetMergeOrder< NetworkType, Config >, and m2etis::pubsub::order::NullOrder< NetworkType >.

template<class NetworkType >

void m2etis::pubsub::order::BaseOrder< NetworkType >::setHn ( const typename NetworkType::Key & self )

inline

sets the hostname of the current node

Definition at line 55 of file BaseOrder.h.

template<class NetworkType >

void m2etis::pubsub::order::BaseOrder< NetworkType >::setRoot ( bool b )

inline

sets whether this node is the root node. Several strategies need this to determind the sequencer

Definition at line 69 of file BaseOrder.h.

Member Data Documentation

template<class NetworkType >

boost::function<void(uint64_t, msgProcess)> m2etis::pubsub::order::BaseOrder< NetworkType >::function_

protected

stores the function to be called for delivering

Parameter (int): specifies the message id that should be further processed

Definition at line 136 of file BaseOrder.h.

template<class NetworkType >

NetworkType::Key m2etis::pubsub::order::BaseOrder< NetworkType >::hn

protected

hostname of the node

Definition at line 130 of file BaseOrder.h.

template<class NetworkType >

bool m2etis::pubsub::order::BaseOrder< NetworkType >::isRoot_

protected

true if this node is the root node

Definition at line 125 of file BaseOrder.h.

template<class NetworkType >

PubSubSystemEnvironment* m2etis::pubsub::order::BaseOrder< NetworkType >::pssi_

protected

Definition at line 120 of file BaseOrder.h.

template<class NetworkType >

boost::function<void(message::OrderInfo::Ptr, const typename NetworkType::Key &, ControlTarget)> m2etis::pubsub::order::BaseOrder< NetworkType >::sendMsg_

protected

stores the function to send new messages This function will send a newly created control message containing the given OrderStruct to the specified sender. The Tree ensures that this message will be sent to the specified receiver and will not be processed by any other strategie.

Parameter (OrderInfo::Ptr): Pointer to the OrderStruct to be used
Parameter (string): Name of the target. This can either be a real node identifier or "root" to send directly to the root of this tree

Definition at line 146 of file BaseOrder.h.

The documentation for this class was generated from the following file:

BaseOrder.h
